Easy Fax settings

With the Easy Fax feature, users can fax their scanned documents in just two steps; all they need to do is tap the Easy Fax button on the home screen of the embedded terminal, and then type the fax number.

By adding multiple Easy Fax action nodes and giving rights to different users or groups, you can create a variety of faxing options for the selected users and groups

To enable the feature on a printing device, you need to enable the Fax module option on its properties panel in MyQ, deactivate and reactivate the device. Go to MyQ, Settings, Configuration Profiles. Select the configuration profile and click Edit (or double-click, or right-click and Edit). The properties panel opens on the right side. In the General tab, mark the Fax module checkbox. Click Save.

On the Parameters tab, you can select from a number of options for each parameter.

All parameters are dependent on the particular printing device type. Therefore, some parameters and/or values might not be available.

Easy Fax Parameters
  • Fax resolution - Resolution of the outgoing fax file. You can select from the following options:

    • Normal

    • Fine

    • Super Fine

    • Ultra Fine

    • Default

  • Duplex - Simplex and Duplex scanning options. You can select from the following options:

    • Single Sided

    • Duplex - binding on top

    • Duplex - binding on side

    • Booklet - binding on left

    • Booklet - binding on right

    • Default

  • Original Image - Determines the way in which the printing device is going to process the scanned page. You can select from the following options:

    • Text + Photo

    • Photo

    • Text

    • Default

  • Size - Size of the scanned input. It determines the size of the scanning area; therefore, it should correspond to the actual size of the scanned paper. You can select from the following options:

    • A3

    • A4

    • A5

    • A6

    • B4

    • B5

    • B6

    • Folio

    • Ledger

    • Letter

    • Legal

    • Statement

    • Oficio II

    • Default

  • Original Orientation - Determines the page's orientation in the outgoing file. The paper's position is relative to the person standing at the printing device. You can select from the following options:

    • Top Edge on Top

    • Top Edge on Left

    • Default

  • Density - Density of the picture in the outgoing file. The higher it is, the darker the resulting picture is. You can select from the following options:

    • Automatic

    • Lowest

    • Lower

    • Low

    • Normal

    • High

    • Higher

    • Highest

    • Default

  • Continuous scan - With the continuous scan option Enabled, scan jobs are not sent until Done is tapped. After clicking Scan, the printing device scans another page. You can select from the following:

    • Disabled

    • Enabled

    • Default

Vendor Compatibility Specifics

Easy Fax compatibility may differ between brands. Please check the relevant terminal documentation for more details.
